Plasticity 26.1.3 for macOS

Industrial designers, game artists, and anyone who needs hard-surface models with precise curves often find traditional CAD too stiff and polygon modelers too loose. Plasticity sits right in that sweet spot. It is a dedicated 3D modeler built on the Parasolid and xNURBS geometry kernels, the same serious math that drives high-end engineering packages, but wrapped in a toolset meant for creative work.

The toolkit gives you precise fillets and boolean operations that produce watertight results, so you can slice, join, and round off forms without the usual cleanup headache. The 2026.1 release also added an Export Hidden Line feature for clean technical SVG output. Updates don't happen by themselves, though — you download and install each one manually. If you lean toward an artist's workflow but need the accuracy of real CAD surfaces, this one clicks.

How Plasticity compares with other Mac 3D apps

Plasticity isn't trying to be everything. It leaves rendering, animation, and sculpting to other tools and focuses on one thing: building clean, precise solid and surface models that feel direct in your hands. That niche puts it up against a few familiar names on the Mac.

Plasticity vs. Blender. Blender is the Swiss Army knife — you get modeling, sculpting, texturing, animation, rendering, and a compositor in one free download. But its standard modeling workflow is mesh-based, and getting Class-A smooth curves or watertight booleans takes extra steps and add-ons. Plasticity skips the bloat and leans entirely on NURBS and solids. If you're designing a product housing or a mechanical part that needs exact radii and G2-continuous blends, Plasticity gets you there faster. Blender wins when the project needs to end in a rendered scene; Plasticity wins when the model needs to be manufacturable.

Plasticity vs. Fusion 360. Fusion is a full engineering platform with history-based parametric modeling, assemblies, CAM, and simulation. It is powerful, but the timeline can feel like handcuffs when you're still exploring shapes. Plasticity uses direct editing — grab a face, push it, type a dimension, and the geometry updates instantly. No tree to scroll through, no feature order to babysit. Fusion makes more sense for a multi-part mechanical assembly with moving joints; Plasticity feels more like sketching in 3D with real numbers attached.

Plasticity vs. Moi 3D. MoI shares a lot of the same philosophy — streamlined NURBS modeling with a clean UI and an artist-friendly approach. MoI leans more toward a pure curves-and-surfaces workflow, while Plasticity brings the Parasolid kernel and a deeper focus on solid booleans and precise fillets. The live dimension system in Plasticity also gives it an edge when you want to tweak measurements on the fly without opening a separate dialog each time.

A real workflow: modeling a small enclosure from scratch

Imagine you need a two-piece plastic enclosure for a small electronics board — something with a curved bottom shell, a snap-fit lip, and a flat top plate. Here's how it might come together in Plasticity.

You start with a sketch on the front plane. Rough out the outer footprint with straight lines and arcs, then use the Live Dimensions to set exact width and depth. Extrude the profile into a solid block — that's your starting blank. A second sketch on the side plane draws the curved bottom profile, and an extrude-cut trims the excess. The boolean operation produces a watertight result without extra stitching.

Next, shell the body to a wall thickness of 2 mm. Plasticity handles uniform wall thickness cleanly, even around the curved bottom. Add a lip around the top edge by sketching an offset profile and extruding it as a new solid, then uniting it with the shell. The xNURBS surface blending comes in where the lip meets the curved wall — you get a smooth G2 transition that would take much longer to set up with polygon tools.

Switch to the top plate. Duplicate the top face of the shell, offset it outward by 0.2 mm for clearance, and extrude it into a separate body. Add screw bosses on the shell interior by sketching circles and extruding with a draft angle. The boolean union merges them into the shell, and a precise fillet on each boss root eliminates the sharp corner in one click.

Before exporting, you run Export Hidden Line on the shell to produce a clean SVG line drawing for documentation — no rendering setup required. The whole model, from first sketch to final fillet, lives inside Plasticity without ever switching to another tool.

When booleans fail on barely touching edges

No software is frictionless, and Plasticity has a few spots where people tend to stumble.

Booleans that fail on "almost-touching" geometry. If two solids barely kiss at a tangent edge or share a coplanar face, the boolean solver can choke. The fix is usually to overlap them slightly — push one body into the other by 0.1 mm before running the operation. Clean intersections make the Parasolid kernel happy.

Fillet ordering matters. Applying a large fillet before a smaller one can collapse adjacent edges and leave no room for the second round. Work from largest fillet to smallest, and if an edge refuses to fillet, check whether nearby geometry has already been softened into a corner that can't take the new radius.

Live Dimensions snapping to the wrong reference. When you click a face or edge to dimension it, Plasticity sometimes grabs a parallel edge you didn't intend. Zoom in, orbit slightly, and click closer to the midpoint of the feature. If the dimension still latches onto the wrong reference, delete it and try with a different camera angle — the picking is view-sensitive.

Export format confusion. Plasticity saves native files but exports to STEP, IGES, OBJ, and others for downstream work. For 3D printing or rendering, STEP preserves

• macOS 10.14 or higher
• Apple Silicon Mac
